JET 287403 JLP-150A-20 JLP-A Series 1-1/2 Ton 20' Lift Lever Hoist
PRODUCT DETAILS
Features
- Safety
- Patented brake wear indicator provides visual indication when to replace worn friction disks
- Weston Style, double pawl brake design splits the load to opposite sides of the ratchet gear for greater load security
- Industrial rated alloy steel hooks rotate 360 degrees for easy rigging
- Hooks slowly stretch to indicate an overload situation increasing jobsite safety
- Durability
- Cast steel safety latches are secured with Allen screws and lock nuts
- Grade 80 black oxide coated for added durability
- Needle bearing design increases efficiency and promotes smooth operation
- Impact resistant all steel construction for added durability and protection
What's in The Box
- 1-1/2 Ton 20' Lift Lever Hoist - 287403
- Owner's Manual
Warranty
- Limited Factory Warranty
- 30 Day Satisfaction Guaranteed
Specifications
| SKU | 287403 |
| Brand | Jet |
| Number of Falls | 1 |
| Lift per Turn | 7/8 in. |
| Load Capacity | 1-1/2 Tons |
| Load Chain Dimensions | 8 x 24 mm. |
| Lever Pull Force (LBF) | 49 |
| Ship Yard Hooks | SV_1375591258806 |
| Lift | 20 ft |
| Headroom | 15 in. |
| Handle Length | 16-1/7 in. |
| Overload Protection | No |
| Hook Throat Opening | 1-6/7 in. |
| Overall Width | 6-7/9 in. |
| Weight | 39 lbs. |
